LED Power Supply-PE-BC Series

Input:100~240Vac, Output: 12V & 24Vdc, 1.25~33A, 30~400W, IP 67 Waterproof power supply

30W–400W Wide Power Range

Available from 30W to 400W, providing flexible power options for different LED lighting applications.

12V / 24V Dual Output Voltage

Supports both 12V and 24V output options for compatibility with a wide range of LED lighting systems.

Up to 93% High Efficiency

High conversion efficiency helps reduce energy loss and improve overall system performance.

Power Factor ≥0.95

High power factor design improves energy utilization and supports stable electrical performance.

IP67 Waterproof & Dustproof

IP67 protection helps prevent water and dust ingress, supporting reliable operation in demanding environments.

Wide Operating Temperature Range

Designed to operate reliably from -40°C to +55°C, supporting various indoor and outdoor applications.

5-Year Warranty

Built for reliable long-term operation and backed by a 5-year warranty.

Multiple Certifications

Certified with CCC, CB, CE, TÜV-Mark and RCM standards for global market requirements.

Contact Us
Poster
Parameter
Size
Video
Download
Message

Product Poster



Technical Parameter

Products Dimensions Output Voltage (V) Output Current (A) Efficiency Power Factor (PF) IP Rating Operating Temperature
PE30-12-BC03 L170*W40*H29 12 2.5 84% ≥0.9 IP68 -40~+55℃
PE30-24-BC03 L170*W40*H29 24 1.25 80% ≥0.9 IP68 -40~+55℃
PE60-12-BC03 L153*W68*H37 12 5 84% ≥0.9 IP68 -40~+55℃
PE60-24-BC03 L153*W68*H37 24 2.5 84% ≥0.9 IP68 -40~+55℃
PE100-12-BC03 L164*W68*37 12 8.33 90% ≥0.95 IP68 -40~+55℃
PE100-24-BC03 L164*W68*37 24 4.17 92% ≥0.95 IP68 -40~+55℃
PE150-12-BC03 L185*W68*H37 12 12.5 90% ≥0.95 IP68 -40~+55℃
PE150-24-BC03 L185*W68*H37 24 6.25 90% ≥0.95 IP68 -40~+55℃
PE200-12-BC03 L217*W68*H37 12 16.67 91% ≥0.95 IP68 -40~+55℃
PE200-24-BC03 L217*W68*H37 24 8.33 92% ≥0.95 IP68 -40~+55℃
PE240-12-BC03 L217*W68*H37 12 20 90% ≥0.95 IP68 -40~+55℃
PE240-24-BC03 L217*W68*H37 24 10 92% ≥0.95 IP68 -40~+55℃
PE300-12-BC03 L251*W86*H42 12 25 92% ≥0.95 IP68 -40~+55℃
PE300-24-BC03 L251*W86*H42 24 12.5 93% ≥0.95 IP68 -40~+55℃
PE320-12-BC03 L251*W86*H42 12 26.67 92% ≥0.95 IP68 -40~+55℃
PE320-24-BC03 L251*W86*H42 24 13.33 93% ≥0.95 IP68 -40~+55℃
PE400-12-BC03 L291*W86*H42.2 12 33.33 92% ≥0.95 IP68 -40~+55℃
PE400-24-BC03 L291*W86*H42.2 24 16.67 93% ≥0.95 IP68 -40~+55℃

Product Size

rishang-led-strip-white-power-supply-pe400-24-bg03-size
