深圳日上光电有限公司

COB Strip-RM0812MC-L
480 Chips/m-12V-8mm-10W/m-Free cutting

 Free cutting, for spaces with high dimensional requirements.

 No soldering wire design,use with matching profiles, plug and play, no need to solder wires.

 Roll-to-Roll Long Plate Process, no welding points, better tensile strength performance.

 Suitable for KTV, shopping mall, cabinet, etc. as corner decoration or contour lighting, etc.


Contact Us
Poster
Parameter
Size
Video
Download
Accessories
Message

Product Poster


Technical Parameter

P/N LED Color CCT (K) CRI SDCM Beam Angle(°) Luminous Flux(Lm/m) Luminous Efficacy (Im/w) Voltage(DC V) Power(W/m)
RM0812MC-L White 2700K ≥90 ≤3 ≥135 470 47 24 10
RM0812MC-L White 3000K ≥90 ≤3 ≥135 500 50 24 10
RM0812MC-L White 4000K ≥90 ≤3 ≥135 550 55 24 10
RM0812MC-L White 6500K ≥90 ≤3 ≥135 550 55 24 10

Product Size

RM0812MC-L 尺寸图 EN

Data Download

Accessories

Dimmer
Dimmer

 Model: KQ1CH-016-A01

 Input Voltage (Receiver): DC12/24V

 Working Voltage (Remote Controller): 3VDC(CR2032 Botton Cell)

 Output Type: PWM output, Constant Voltage

 Output Current: 1 Channel,≤8A per channel

 Output Power: 12V<96W ,24V<192W

 Output Signal: 2.4GHz

 Light: Single Color

 Control Sector: Single Sector

 Standby time: 12 Months

 Control Distance: 30 Meters

Cable-Board Connector
Cable-Board Connector

 Application: 8mm

 Model:  1CN-07-205

Cable-Board Connector
Cable-Board Connector

 Application: 8mm

 Model:  1CN-07-206
